Features / Specifications:
- 50 Ohm input / Output Impedance
- 9 pole Chebyshev design
- Low insertion loss < 0.1dB
- Low input VSWR <1.15:1
- Suitable for 12m 11m and 10m bands, Cut off frequency 36MHz
- Maximum power 600W constant carrier / 1200W SSB
- Stopband attenuation >50dB@55 MHz >70dB@100MHz
- SO239 Input and Output connectors with Teflon insulator and gold-plated terminal
- Dimensions: L 230mm, W 50mm, H 40mm
- Weight: 480g
